Compuerta de velocidad de acero inoxidable
IM.ST605
Stainless steel speed gate IM.ST605 is a high performance, casi, safe, and smart stainless steel speed engineered pedestrian flow. A minimalistic design, its firm construction, and high level of security i.e. anti-tailgating and emergency override, makes it easy to install it at the high traffic location not only in the corporate lobbies and industrial locations but also in the government facilities.
-
Material：Acero inoxidable 304
-
Infrared Detection Sensor：8 Pares
-
Ancho de canal ：≤1000mm
-
Velocidad del tráfico： ≤ 45 personas/min
-
Dimensions（Customization Accepted）：largura 1500* Ancho 127* height 980mm
Reconocimiento facial
Pantalla LED
8 Pares de detectores infrarrojos
QR
The stainless steel speed gates are well designed to occupy the location where there is a need of high throughput and at the same time, have high degree of security. The size of the gate is small and minimalist in nature. The high-speed wing mechanism is directly sensitive to the accepted credentials such as the RFID cards, QR code or any other biometric entry. Mientras tanto, it has got in-car anti-tailgating sensors that regulate the passage in real time to prevent illegal trailing. It possesses a noise-free motor drive that has a high-quality brushless motor that makes it ideal to be utilized in areas where noise is a sensitive factor.
Funciones
- Less than 1s latency of wing opening.
- SUS304 anticorrosion stainless steel body.
- Tailgating infra-red sensor detection system.
- Directed access LED displays and voice announcements.
- RFID, QR code and biometric compatible.
- Auto-open of power failure or fire alarm.
- Neutral brushless low noise motor drive.
- Supports one directional access control or two directional access control.
Además, the system facilitates the unidirectional flow and the bidirectional flow. With modular internal parts, the workload on the maintenance is minimized and the downtime is minimized. The speed gate is stainless steel which offers quality, fashionable and intelligent access control either on its own or when used along with a larger access control system.
- Detalles del producto
- Características técnicas
- Técnicos y características
- Adaptabilidad
- Aplicación
Detalles del producto
Material y estructura de grado industrial
Our stainless steel speed gate is a high-performance, slim-profile access control solution designed for fast, seguro, and efficient pedestrian management. Built with heavy-duty 304 or 316 Acero inoxidable, it ensures long-lasting durability, corrosion resistance, and a sleek modern appearance, making it ideal for both indoor and outdoor installations.
Engineered for high-traffic environments, this speed gate offers rapid operation, low maintenance, and seamless integration with various access control systems (card readers, Escáneres biométricos, Reconocimiento facial, etcetera.). Its simple yet robust design makes it a reliable choice for corporate offices, Centros de transporte, Estadios, fábricas, and secure facilities.
Características técnicas
Especificaciones técnicas básicas
| Dimensiones | largura 1500* Ancho 127* height 980mm |
| Material | 1.5SUS de mm de espesor 304 Acero inoxidable |
| Sistema de detección | 8-Sensores infrarrojos puntuales (ampliable a 12 Pares) |
| Sistema de transmisión | Servomotor (30 Ciclos M+ sin mantenimiento) |
| Velocidad de adelantamiento | ≤ 45 personas/min |
| Ancho de paso | 550-900mm estándar (expandable to 1300mm barrier-free access) |
| Tensión de alimentación | AC110~220V±10%，50/60Hz |
| Integración | Soporta interfaces de RFID/reconocimiento facial/escaneo QR/RS485/relés |
Técnicos y características
Características técnicas y de seguridad
Authentication and Access Control
Multi-Mode Verification:
RFID-cards, QR-codes, biometría (fingerprint/face recognition), mobile NFC, as well as PIN pads are accepted.
Integration Capability:
This can be connected with third party security systems (P ej.., turnstile controllers, ticketing systems, visitor management software).
Direction Control:
The direction control may be unidirectional, bidirectional and free flow passage.
Fast & Smooth Gate Movement
High-Speed Swing Mechanism:
It requires 0.5-1 seconds to transport an arm in case of high pedestrian throughput.
Motorized Operation:
The operation uses a 24 V DC brushless motor that offers the benefit of providing efficiency in energy usage and giving it a quiet operation.
Anti-Rebound Function:
This prevents forced entry to the lock by locking the arm when it is hampered when trying to close.
Anti Tailgating/Safety Features
Infrared Sensors (IR):
IR sensors to curb tailgating/piggybacking passage are 8-12 in number.
Obstruction Detection:
This will automatically stop or reverse the arm in case an object/person is detected in the course of the path.
Anti-Pinch Protection:
These are force sensitive mechanisms or edges made of soft rubber with the purpose of preventing injury.
Emergency Override: Free Push Mode:
When the power is off or necessary (connection to fire alarm).
Fire Alarm Interface:
Auto unlock mode.
LED & Audio Indicators
Visual Signals:
RED LED: Denied access / locked gate. Green LED: Licensed / unlocked gate. Selectable 7-digit showing of countdowns or error codes.
Audible Notifications:
The audible notifications are the use of a buzzer or vocal warning during invalid access or system failure.
Durability and Green Flexibility
Stainless Steel Housing:
It is not vulnerable to corrosion, impact and vandalism.
IP65 Waterproof Rating:
Protects internal components against dust and rain (IP67 optional to be immersible).
High Temperature Tolerance:
Will operate in -20 o C to 70 o C -4 Para 158 F.
Adaptabilidad
Adaptabilidad al mercado global
- Voltaje: 100-240V entrada de amplio alcance (Compatibilidad global de red)
- Soporte lingüístico: 24/7 Servicio en Inglaterra
- Certificación：ESE,FCC,ISO
Aplicación
Escenarios de aplicación
- Oficinas corporativas & Business Centers
- Estadios, Arenas & Event Venues
- Fábricas & Industrial Facilities
- Edificios gubernamentales & High-Security Areas
- Universities & Research Centers
- Shopping Malls & Smart Buildings
